Three Layer ABC Blown Film Machine
mm
micron
Flexible Design for Plastic Film Producers
The 3-layer ABC blown film co-extruder is equipped with 3 extruders. This is capable of producing a three-layer plastic film of different materials (LDPE, LLDPE, HDPE, recycled, biodegradable) or different colors (pigmentation) in each layer. The design of the head ensures a good separation of materials and colors in each layer (A, B, and C), thus giving greater flexibility to producers with a single machine.
Blown Film Machines Catalog
-
3-color Stripe Film -
Agricultural Film -
Construction Film
-
T-shirt Bags -
Table Cover -
Supermarket Bags
Model Name
CE-ABC / Tri-X
Final Product
HDPE/LDPE/LLDPE film
Application
Agricultural films, construction cover, dust covers, furniture covers, pillow/mattress bags, 3 color stripe film, T-shirt bags
Material used
Recycled material, HDPE/LDPE/LLDPE blend, biodegradable or virgin raw material
Output Range
20kg ~ 250kg (customized)
Film Layer
Three layer
Screw Diameter
45 mm, 55 mm and 65 mm
Screw L/D
28/1 or 30/1
Screw Material
SACM-645
Width
150mm ~ 2500mm (customized)
Thickness
10-200 microns
Optional Devices
In-line printer, Dosing system, Rotary die device, Corona treater, EPC (Edge position control), Slit and seal knife, Hydraulic unloading device, Automatic double winder, Tension control system
Warranty
1 year
Delivery Time
120-180 days
Technical Assistance
After-sales service provided: Engineers available to service machinery overseas
